Industrial PoE Injector & Splitter

Ethernet Direct offers Gigabit High Power PoE+ Injectors that combines power and data and delivers them to a powered device over one Ethernet cables as well as PoE splitters to split power and data from PoE equipments.



PoE splitter

  • IEEE 802.3af compliant; splits power and data from PoE equipment
  • Supports output power up to 15.4W at 24 VDC via a removable terminal blocl
  • Short circuit protection for power output

PoE injector

High Performance Network Switching Technology

  • Complies with IEEE standards
  • Provides 1 x 10/100/1000Base-T(X) with RJ-45 connector as data port
  • Provides 1 x 10/100/1000Base-T(X) with RJ-45 connector as PoE injector port
  • Supports DIP switches to select PoE power output at 15.4W/30W/36W/60W/72W
  • Supports DIP switches to select PoE operating mode A or B

Reliable Power Design

  • Equipped with redundant power inputs
  • Supports 12/24/48VDC power input
  • Power reverse polarity protection and overload current protection
  • Built-in high efficiency power booster to cater for the PoE/PoE+ requirement

Robust Industrial Design

  • EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
  • EN 50121-4 certified for Railway Applications (Track Side)
  • Robust industrial design case complies with IP30 housing standard
  • Supports operating temperature -10 to 60°C & extended temperature -40 to 75°C
  • DIN-Rail or optional wall mounting installation
