Industrial PoE Gigabit Switches

Ethernet Direct offers the latest technologies in Power over Ethernet supporting IEEE 802.3af, 802.3at and 802.3bt. Our switches support a wide variety of Ethernet functions including STP/RSTP/MSTP/ ITU-T G.8032 ERPS as well as advanced PoE management functions such as weekly PoE power scheduling, device auto-checking and auto-reset.

Ethernet Direct offers the latest technologies in Power over Ethernet supporting IEEE 802.3af, 802.3at and 802.3bt. The switches can be used to power IEEE 802.3af/at compliant powered devices (PD), eliminating the need for additional wiring and provide an economical solution for your industrial Ethernet network.



Product Features

Ethernet Direct offers the latest technologies in Power over Ethernet supporting IEEE 802.3af, 802.3at and 802.3bt. Our switches support a wide variety of Ethernet functions including STP/RSTP/MSTP/ ITU-T G.8032 ERPS as well as advanced PoE management functions such as weekly PoE power scheduling, device auto-checking and auto-reset.

High Performance Network Switching Technology

  • Complies with IEEE standards
  • Provides multiple Gigabit TX ports with RJ-45 connector with supporting of Green Ethernet IEEE802.3az EEE (Energy Efficient Ethernet)
  • Provides multiple Gigabit SFP slots with supporting of DDMI
  • Advanced PoE Management, PoE PD Failure Auto Checking and auto reset when PD fail, PoE port on/off weekly scheduling, PoE configuration for power planning
  • Supports various network redundant solutions, including Direct-Ring, Direct-Chain, Join-Ring, STP, RSTP, MSTP and ITU-T G.8032
  • Proprietary ultra high speed redundant technology with < 10ms recovery time @ 250 devices
  • Supports IEEE1588 PTP V2 for precise time synchronization, to operate in Ordinary-Boundary, Peer to Peer Transparent Clock, End to End Transparent Clock, Master, Slave mode by each port
  • Supports various network security solutions, Port and MAC based IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, SSL/SSH v2
  • Supports DHCP Server/Client/Relay/Snooping/Snooping option 82/Relay option 82
  • Network traffic priority, QoS, Traffic classification QoS, CoS, bandwidth control for Ingress/Egress, broadcast storm control, DiffServ
  • Supports IEEE802.1Q VLAN, MAC-based VLAN, IP Subnet-based VLAN, Protocol-based VLAN, VLAN translation, GVRP/MVRP
  • Supports IGMP/MLD snooping V1/V2/V3, IGMP Filtering/Throttling, IGMP query, IGMP proxy reporting, MLD snooping
  • Supports dynamic IEEE 802.3ad LACP Link Aggregation, Static Link Aggregation
  • Supports RMON, MIB II, Port mirroring, Syslog, IEEE802.1ab LLDP for network monitoring
  • Supports IPv6 Telnet server, ICMPv6
  • Supports CLI, Web based management, SNMP v1/v2c/v3, Telnet server for management
  • Supports firmware upgrade via TFTP & HTTP with redundant firmware option

Reliable Power Design

  • Supports 48/-48VDC redundant power input for CMG-428G and CMG-1688G series
  • Supports 24/48/-48VDC redundant power input with built-in very high efficiency booster to rise up 55 VDC for PoE output for Z1AT models
  • Supports negative voltage power input with isolated RS-232 console port
  • Regulated PoE output voltage (55VDC) to stabilize PoE device, and guarantee delivery PoE power distance to 100m
  • 2.25K VDC Hi-pot isolation protection for Ethernet ports and power
  • Provides 4/8 port IEEE802.3af/802.3at PoE+ output, 30W per port
  • Provides 4 port IEEE802.3af/802.3at/802.3bt PoE++ output, 60W per port for CMG-428GEPTZ2BT
  • Power reverse polarity protection and overload current protection

Robust Industrial Design

  • UL60950-1, CE, FCC certified
  • EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
  • NEMA TS-2 certified for Traffic Control
  • EN 50121-4 certified for Railway Applications (Track Side)
  • Robust industrial design case complies with IP30 housing standard
  • Supports operating temperature -10 to 60°C & extended temperature -40 to 75°C
  • DIN-Rail or optional wall mounting installation



Product Features

Ethernet Direct offers the latest technologies in Power over Ethernet supporting IEEE 802.3af, 802.3at and 802.3bt. The switches can be used to power IEEE 802.3af/at compliant powered devices (PD), eliminating the need for additional wiring and provide an economical solution for your industrial Ethernet network.

High Performance Network Switching Technology

  • Complies with IEEE standards
  • Provides multiple Gigabit TX ports with RJ-45 connector
  • Provides multiple Gigabit SFP slots or SC connectors
  • Provides DIP switch to switch on/off of the alarm relay, broadcast storm protection and setting up the transmission speed of the SFP slot

Reliable Power Design

  • Supports 48VDC redundant power input for CUG-428GEBT
  • Supports 24/48VDC redundant power input with built-in very high efficiency booster to rise up 55 VDC for PoE output for AT models
  • Regulated PoE output voltage (55VDC) to stabilize PoE device, and guarantee delivery PoE power distance to 100m
  • Provides 4 port IEEE802.3af/802.3at PoE+ output, 30W per port
  • Provides 4 port IEEE802.3af/802.3at/802.3bt PoE++ output, 60W per port for CUG-428GEBT
  • Power reverse polarity protection and overload current protection

Robust Industrial Design

  • UL60950-1, CE, FCC certified
  • EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
  • EN 50121-4 certified for Railway Applications (Track Side)
  • Robust industrial design case complies with IP30 housing standard
  • Supports operating temperature -10 to 60°C & extended temperature -40 to 75°C
  • DIN-Rail or optional wall mounting installation
